Digi XBee XR 920

Coming soon

The Digi XBee XR family operates in the 920.5 to 928.1 MHz range, delivering superior performance and interference immunity


Digi XBee XR 900 MMT RF pad Digi XBee XR 900 MMT RF pad front Digi XBee XR 900 MMT RF pad back Digi XBee XR 900 MMT U.FL Digi XBee XR 900 MMT U.FL front Digi XBee XR 900 MMT U.FL back Digi XBee XR 900 Development Kit Digi XBee XR 920 application example
  • Fully certified for use in unlicensed 920 MHz band
  • RF module based on Silicon Labs EFR32 microcontroller
  • Design includes SAW filter for optimal performance in noisy RF environments
  • 256-bit AES encryption for secure data communication
  • DigiMesh® networking topology for redundancy and reliability
  • Simple configuration using Digi XCTU® accelerates time to market
  • Digi XBee Tools to simplify tasks and get to market faster

The Digi XBee® XR 920 Japan module is a compact and reliable solution supporting deployment of long-range connectivity applications. The pre-certified module operates between 920.5 and 928.1 MHz in compliance with standards.

Secure, robust and reliable

The Digi XBee XR 920 Japan modules can be configured easily using Digi’s easy-to-use XCTU® software or via Digi’s simplified AT or API command sets. They are pre-certified and include integrated antennas, removing the burden of RF development/ support costs and enabling fast time to market for OEM designs. The utilization of Frequency Hopping Spread Spectrum (FHSS) on the XBee XR along with an industrial temperature range of −40 °C to 85 °C (−40 °F to 185 °F) make it ideal for applications in noisy, challenging environments.

The module supports both point-to-point and mesh networking protocols (DigiMesh®), with a line-of-sight range up to 8.5 kilometers. It is well suited for agriculture and energy applications where long-distance communication is required.

The Digi XBee XR 920 Japan RF module is a complete hardware and software solution that works directly out of the box. Development kits along with Digi XBee Tools support the complete IoT application lifecycle, from evaluation, testing and prototyping through manufacturing and deployment to long-term network management.

XCTU

Next Generation Configuration Platform for Digi XBee

  • XCTU is free and compatible with Windows, MacOS and Linux.
  • Simple wireless network configuration and architecture.
  • Simple development tool for quickly building XBee API frames.
  • Explore and read firmware release notes.
Learn More
Digi XBee Tools

Develop, Build, Deploy and Manage Your Digi XBee Network

Digi XBee® Tools

Digi XBee Tools support the complete IoT application lifecycle, from the evaluation, testing and prototyping phase through manufacturing and deployment to long-term network management. See how Digi XBee Tools simplify tasks and help get to market faster.

Discover Digi XBee Tools

Compare Sub-GHz Wireless OEM RF Modules

Compare Sub-GHz Wireless OEM RF Modules
Digi XBee XR 920 Development Kit — Japan
SKU: XK-9XR-DMM-5 Coming soon
Digi XBee XR 920 Development Kit — Japan
XK-9XR-DMM-5 Contact Us
Digi XBee XR 920 Micro-Mount (MMT) Modules — Japan
SKU: XB-9XR-DMRM-051 Coming soon
Digi XBee XR 920 MHz, DigiMesh, RF pad, MMT — Japan
XB-9XR-DMRM-051 Contact Us
SKU: XB-9XR-DMUM-051 Coming soon
Digi XBee XR 920 MHz, DigiMesh, U.FL, MMT — Japan
XB-9XR-DMUM-051 Contact Us
Services and Support
Digi XCTU
XCTU is a free multi-platform application designed to enable developers to interact with Digi RF modules through a simple-to-use graphical interface. It includes new tools that make it easy to set-up, configure and test XBee® RF modules.
  Get Started
Digi Remote Manager
Digi Remote Manager is the technology platform enabling and automating the deployment, monitoring and management of thousands of devices from a single point of command. Compare Digi’s multiple offerings and varying subscription terms to meet your business needs.
  Get Started
Wireless Design Services
Digi wireless design services help companies solve business problems by embedding wireless technologies to create innovative M2M products
  Get Started
Specifications Digi XBee XR 920 Japan
HARDWARE
PROCESSOR EFR32FG13P231F512 transceiver at 40 MHz
FREQUENCY BAND 920.5 MHz – 928.1 MHz
AVAILABLE FORM FACTORS Micro-mount (MMT)
ANTENNA OPTIONS MMT: U.FL connector, RF pad
WEIGHT MMT: 1.2 g (0.042 oz)
DIMENSIONS MMT: 13 mm x 19 mm x 2 mm (0.533 in x 0.76 in x 0.087 in)
PERFORMANCE
RF DATA RATE Low data rate: 10 kbps; high data rate: 110 kbps
UART DATA RATE Up to 921.6 kbps
SPI DATA RATE Up to 5 Mbps
LINE-OF-SIGHT RANGE* Up to 8.5 km (5 mi) rural, up to 1.5 km (1 mi) urban
INDOOR RANGE Up to 70 m (230 ft)
TRANSMIT POWER Up to 13 dBm ERP
RECEIVER SENSITIVITY Low data rate: −113 dBm; high data rate: −108 dBm
RECEIVER RF SENSITIVITY Below 900 MHz and above 930 MHz; >70 dB
FEATURES
DIGITAL I/O 15
AVAILABLE CHANNEL FREQUENCIES 38 channels
ANALOG INPUTS (4) 10-bit ADC inputs
OPERATING TEMPERATURE −40 °C to 85 °C (−40 °F to 185 °F)
NETWORKING TOPOLOGIES Point-to-point/point-to-multipoint, DigiMesh; SX protocol compatible
SECURITY 256-bit AES Encryption
POWER
SUPPLY VOLTAGE 2.1 - 3.6 VDC, 3.3 VDC typical
TRANSMIT CURRENT 79 mA
RECEIVE CURRENT 28 mA
SLEEP CURRENT 1.2 uA
REGULATORY APPROVALS**
ROHS Yes
MIC-TELEC (JAPAN) Yes

*Range figure estimates are based on free-air terrain with limited sources of interference. Actual range will vary based on transmitting power, orientation of transmitter and receiver, height of transmitting antenna, height of receiving antenna, weather conditions, interference sources in the area, and terrain between receiver and transmitter, including indoor and outdoor structures such as walls, trees, buildings, hills, and mountains.
**Visit product certifications for latest updates.
